Brand Name : Hongruntong Marine
Model Number : HM-FDH5
Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Place of Origin : China
MOQ : 1
Price : USD95 to USD990 Per Piece
Payment Terms : L/C,D/A,D/P,T/T,Western Union
Supply Ability : 3580 Pieces Per Month
Delivery Time : 5-6 Work Days
Packaging Details : Wooden Pallet, Wooden Case
Product Name : Floating Dredge Hose
Inner Rubber : NBR
Reinforcement : High Strength Synthetic Cord with Sprial Steel Wirehose
Keywords : Floating Discharge Hose Pipe
Warranty : 24 Months
Pressure : 10-21 Bar
Flange : ANSI150, ANSI300
Size : Customized Size
Hongruntong Marine Floating Dredge Hose is a heavy-duty, self-floating rubber hose specially engineered for dredging, sand excavation, sludge transportation, and marine water discharge applications.
Built with high-strength steel wire reinforcement and premium rubber compounds, our floating dredge hose delivers exceptional buoyancy, high pressure resistance, superior wear resistance, and excellent flexibility. It performs reliably in demanding marine, offshore, and river environments, efficiently conveying seawater, silt, sand, and slurry over extended distances.
With over 30 years of manufacturing expertise, we maintain strict quality control throughout every production stage to ensure consistent performance, reliable sealing, and extended service life. Our floating dredge hoses are widely utilized in port construction, river dredging, land reclamation, and offshore engineering projects, earning global customer recognition.


| Material | PTFE, Galvanized Steel Wire, PVC Coated Polyester Cloth |
| Product Name | Floating Dredge Hose |
| Inner Wire | Stainless Steel 316 |
| Lining | Polyamide |
| Carcass | Polyamide fabrics, Polyester films |
| Outer Wire | Stainless Steel 316 |
| Working Pressure | 10 bar to 21 bar |
| Maximum Length | 40 meters |
| Sample | Available |
| Delivery Time | Normally 3-5 days |
| Model | Dimensions (mm) | Dimensions (inch) | Working Pressure (bar) | Working Pressure (psi) | Safety Factor | Bending Radius (mm) | Weight (kg) | Length (m) |
|---|---|---|---|---|---|---|---|---|
| HM-FDH20 | 20 | 3/4" | 16 | 230 | 6:1 | 80 | 0.8 | 40 |
| HM-FDH25 | 25 | 1" | 16 | 230 | 6:1 | 100 | 1 | 40 |
| HM-FDH32 | 32 | 11/4" | 16 | 230 | 6:1 | 125 | 1.3 | 40 |
| HM-FDH40 | 40 | 11/2" | 16 | 230 | 6:1 | 140 | 1.5 | 40 |
| HM-FDH50 | 50 | 2" | 16 | 230 | 6:1 | 180 | 2.5 | 40 |
| HM-FDH65 | 65 | 21/2" | 16 | 230 | 6:1 | 200 | 3.3 | 40 |
| HM-FDH80 | 80 | 3" | 16 | 230 | 6:1 | 260 | 4 | 40 |
| HM-FDH100 | 100 | 4" | 16 | 230 | 6:1 | 380 | 6.8 | 40 |
| HM-FDH125 | 125 | 5" | 16 | 230 | 6:1 | 440 | 9.2 | 40 |
| HM-FDH150 | 150 | 6" | 16 | 230 | 6:1 | 500 | 13.2 | 40 |
| HM-FDH200 | 200 | 8" | 16 | 230 | 6:1 | 750 | 18 | 40 |
| HM-FDH250 | 250 | 10" | 16 | 230 | 6:1 | 900 | 26 | 25 |
*Note: Various sizes can be customized according to project requirements.
Our floating dredge hose features high-strength steel wire reinforcement, supporting pressure levels from 0.5MPa to 2.5MPa to accommodate various dredging and offshore working conditions.
It incorporates high wear-resistant rubber for the inner layer, high-strength cord and steel wire for reinforcement, closed-cell buoyancy foam for floating, and weather-resistant rubber for the outer layer, ensuring durability and operational stability.
Yes. We provide comprehensive customization options including diameter, length, flange type, pressure rating, and connection mode tailored to your specific project requirements.
It is widely used in port dredging, land reclamation, river and lake desilting, offshore sand extraction, and long-distance slurry transportation under challenging marine environments.
With premium rubber materials and strict production quality control, our hose delivers exceptional wear, aging, and corrosion resistance, providing significantly longer service life than standard hoses in heavy-duty dredging applications.



|
|
